Description
- The controller is generally part of the control panel and in such a case the terminals should not remain accessible to the user after installation.
Jumbo Display Indicator
Jumbo Display Indicator
Jumbo Display Indicator
Make: Aavad
Model: PI-JD-4
Sensor input: T/C: J, K, R, S, RTD: PT-100
Resolution: T/C: 1°C & Pt-100: 1°C/ 0.1°C
Analog input: 0 – 20 mA, 4 – 20 mA, 0 – 1 Vdc, 0 – 5 Vdc, 0 – 3.3 Vdc, 0 – 10 Vdc (selectable)
Range: -1999° To 9999℃
Display height: 4.0 “(Pv)
Display color: Red
Sampling rate: 250 msec
Accuracy: 0.3% Fs
Supply voltage: 90 – 270V ac/ dc (24V dc available on request)
Ambient temperature: 0 To 50℃
Humidity: 95% Rh (non-condensing)
Additional information
| Weight | 1.5 kg |
|---|
