Loop Power Indicator

Loop Power Indicator

SKU: FLP-TT Category:

Loop Power Indicator With Local Display

Special features:

Programmable for all input type & range

Universal input (RTD, thermocouple, ohm, V, mV)

4 digit 0.56″ led

1.5 kV RMS isolation between input & output

High accuracy

Linearized output

Fast response time: <500 ms

Input and output scaling

Reverse polarity protection

Direct/reverse output

Sensor break detection

Digital filter Modbus tester software for configuration, calibration & monitoring



Technical specification:

Input: Pt100 3-wire, Pt100 4-wire

Sensor current: 0.2mA

Potentiometer/ resistance: 0-2500ω, 5000ω

Thermocouple (with internal and

External ambient sensor

(Rtd-3wire sensor)): E, J, K, T, B, R, S, N

V: 0-5Vdc / 0-10Vdc
mV: 0-75mV/ 0-500 mV dc

Input impedance: > 1m ohms

Sensor break current: <1 Ua

Zero: through Modbus tester

Span: through Modbus tester

Accuracy

E, J, K, T, N, PT-100, MV, Ω: 0.1% OF FS

B, R, S: 0.25% oF FS

Cjc error

E, J, K, T, N: ±2 ºC

R, S: ±3 ºC

Response time: < 0.5 sec

Stability: ±0.1% per year

Digital filter: 0-20 sec settable through software (2 sec default)

Cmrr: > 130 db

Nmrr: 40 db

Temp-co: <150 ppm

Output: 4- 20mA

Description

  • Aavad make a 2-wire loop powered & fully programmable universal flameproof temperature transmitter with display, designed for isolated and accurate temperature measurements and signal conditioning applications.
