Mack: Aavad
Dial Size: 63 mm
Range: 0 to 100˚C
Configuration: Bi-metal Strip
Case & Bezel: SS 304, Bayonet Type
Stem OD × Length: 8 × 100 mm
Dial: Aluminium, Black Markings on White Background
Pointer: Aluminium, Black
Window: Shatterproof Glass
Accuracy: +/- 1.6% of FSD
Over-Range Protection: 130% of FSD
Connection: 1/2″ Bsp (M) Fix Fitig
Mounting: Direct bottom connection
Temperature gauges measure the thermal state of a homogeneous substance. The measuring system must be brought as closely together as possible with the body to be measured. The most widely used measuring methods for temperature measurement rely on temperature-dependent characteristics of the body and substance.
