Mud Pressure Gauge
Mud Pressure Gauge
Pressure Gauge
| Parameter | Specification |
|---|---|
| Make | Aavad |
| Dial Size | 100 mm |
| Dial | Aluminium, Black Markings on White Background –1) Rotating Type Dial2) Rotating Pointer Fixed Dial |
| Pointer | Aluminium, Red – Fixed Type pointer |
| Range | 0 to 6000 PSI |
| Case& Bezel | SS – 304 Heavy Constructed |
| Accuracy | + /- 2.0% of FSD |
| Over-Range Protection | 130% of FSD |
| Diaphragm | SS 316L |
| Dampener | In-built |
| Mounting | Direct Bottom |
| Connection | 2″ NPT (F) |
| MOC | All SS |
| Window | Shatterproof Glass |
| Glycerine Filled | Yes |
Description
Aavad Instrument Pvt. Ltd.’s Mud Pressure Gauge is a rugged, heavy-duty pressure gauge specifically engineered for drilling fluid (mud) pressure measurement in oil & gas exploration, directional drilling, water well drilling, and foundation engineering applications. The gauge is designed to withstand the highly abrasive, viscous, and particle-laden nature of drilling mud, which would rapidly clog or damage conventional Bourdon tube gauges.
Mud Pressure Gauge are extremely accurate and widely used in the harshest drilling environments. Each of our mud pressure systems are designed to meet or exceed up to industrial standards. Our mud pump pressure gauges to stand up to whatever the oil and gas industry can throw at them.
